NM-DVR1004 Camera Device

Product Features

Penta-brid video input

1080p preview support

Face detection

H.265 / smart h.265 video compression

2 SD Card Support

web viewer, cms and dmss

Areas of Use

Fleet Management

Car Tracking

Logistics Management

NM-DVR1004 Camera Devices

In security camera systems, camera devices appear with mobile NVR system or mobile DVR System. NM-DVR 1004 camera devices are device types that include a mobile DVR system and record the incoming image. It converts the signals from security cameras into digital form and transfers them to other devices by storing data. NM-DVR1004 has a compact design and is used in many security systems. DVR1004 camera recorders have features such as remote monitoring, backup storage, playback, audio and video recording. Optionally, DVR camera devices can have channel options such as 4-8-16-32-64. NM-DVR1004 camera devices come with 4 channels and 1080p real-time recording feature. In addition, NM-DVR1004 camera devices stand out with advanced Network function features. Built-in high precision GPS module, wireless connection modules are among the features of the NM-1004 camera with tracking device.

What are NM-DVR1004 Camera Devices?

NM-DVR1004 camera devices are devices that record the images transferred from the cameras in the security system. Video recorders, which record videos in compressed form, serve to store this data and transfer it to other devices. At this point, DVR1004 product technical features stand out with its many functions and ergonomic design. High image quality, 800×600 screen resolution, camera mode consisting of manual, timing and stop options are the main important features of the device. Other prominent features of NM-DVR1004 vehicle tracking system camera devices are as follows:

Penta-Brid (HDCVI / AHD / TVI / CVBS / IP) Video Input: The product is technically compatible with various video inputs.
H.265 / Smart H.265 Video Compression: It includes H.265 video coding technology that allows videos to be reduced in size.
4 Channel 1080P Resolution Preview Support: The real-time recording feature offered with high resolution includes a 4-channel option.
High Resolution Display: The device has a screen with 800×600 dimensions and 1.04.2006 split screen feature.
2 SD card support: The product, which stands out with its memory card feature, has the ability to use 2 SD cards, each 256 GB in size.
Face Detection Feature: DVR1004 camera devices include a quality video recording option with motion and face detection feature.
Multiple Monitoring: It provides accessibility from many different points with its web viewer, CMS (DSS) and DMSS feature.
Playback Function: The device includes commands such as play, stop, rewind, fast or slow play, previous-next camera, repeat, digital zoom and more.
GPS: NM-DVR1004 camera devices include a high precision GPS module in their specifications. This feature is optional.
NM-DVR1004 Camera Devices Usage Areas

One of the biggest security measures in daily life is camera systems. NM-DVR1004 digital camera devices, which are part of these systems, find their place in many areas. NM-DVR1004 Camera Devices usage areas are mainly as follows:

In various service sectors,
In areas such as workplaces, private property,
Public buildings,
Access and control systems,
NM-DVR1004 camera devices are preferred in every area that requires security measures.
Why Should You Buy NM-DVR1004 Camera Devices?

In-car camera devices are used at many points as a company or individually. NM-DVR1004 camera devices, which provide general security, exhibit superior performance. In terms of use and application, the devices have state-of-the-art equipment. Video compression technology, storage capacity and motion detection features in the device make it one step ahead of its competitors. In addition, DVR1004 camera devices have affordable cost and easy installation. In addition, high video quality and playback function features are among the reasons why the device is preferred. This product, which consists of mobile DVR systems, reflects its difference with its camera features. All these technical details and aesthetic design are the reasons to buy NM-DVR1004 camera devices.

In addition, apart from NM-DVR-1004 devices, NM-NVR camera device type with NVR system, there are different technical specifications.

You can evaluate various security camera device options on our site as a solution alternative.

In Which Solutions Are NM-DVR1004 Camera Devices Used?

NM-DVR1004 camera devices, which have a compact structure, are enriched with hardware according to the need. It has features such as backup, recording, recording replay in providing security. At this point, it can be integrated into all security systems. In addition, it has 138mm × 160mm × 49mm dimensions in case size and has very ergonomic dimensions with a net weight of 0.97 kg. NM-DVR1004 sensitive vehicle camera is used in many solution alternatives with all these functions.

NM-DVR1004 Camera Devices Software

The device feature, which appears as DVR, has its own system features. NM-DVR1004 is one of the digital video recorders used in CCTV systems. Devices are produced with special software and qualifications in this direction. Basically, the analog signals received from the security camera are converted into digital format with this device. Again, thanks to the system, these digital signals are stored on the hard disk in the device and transfer the video stream to other devices. All these operations are programmed with special software of NM-DVR1004 camera devices. This system offers quality and long-lasting performance.

NM-DVR1004 Camera Devices Order

NM-DVR1004, one of the video recorders, is offered for sale together with other solution alternatives. Products with different functions that will suit your needs and meet your expectations are available with a phone call. You can contact us to order all the products we offer or to get detailed information. You can call our call center by dialing 0 850 433 18 18. You can also request a meeting by filling out the form on the side. If you fill out the form or call us, we assure you that we will return to you in a short time.

Thank you for your interest in our products.

Frequently Asked Questions (FAQ)
What are Digital Video Recorders-DVR?

Digital Video Recorders or DVRs are image recorders that convert and record analog video signals. The products, which are connected to the camera system, store and store incoming data. These devices, where images can be monitored, are produced with various features.

What Should Be Considered When Buying a DVR Camera Device?

When buying a DVR camera device, you should pay attention to the number of supported cameras, video compression technology and storage capacity. In addition, face detection and resolution features are also very important. NM-DVR1004 camera devices are unique in all these points in camera features.

How Can I Order a Digital Video Recorder?

You can contact our call center at 0 850 433 18 18 to order NM-DVR1004 camera devices. You can also contact us by filling out the form on our page.

FeatureValue
Main Processor
Embedded Microprocessor
Operating SystemEmbedded LINUX
Video Inputs4 channels HDCVI / AHD / TVI / CVBS (Supports audio when connecting AHD / TVI cameras) + 1 channel 4MP IPC
Two-Way Audio1
Display
Interfaces2 TV (1 aviation connector)
Resolution800 x 600
Split Screen1.04.2006
Privacy Masking4 rectangular zones (per camera)
OSDChannel name, time, GPS, license number
Video CompressionH.265 / Smart H.265 / H.264 / Smart H.264
Audio CompressionG.711A / G.711U / PCM
Resolution4 channels @ 1080P real-time recording
Recording ModesManual, Timing (Regular (Continuous), MD, Alarm), Stop
Recording Interval1 ~ 120 minutes (default: 60 minutes), Pre-record: 1 ~ 30 seconds, Post-record: 10 ~ 300 seconds
Triggered EventsRecording, PTZ, Tour, Alarm, Email, FTP, Buzzer, and Screen tips
Video DetectionMotion Detection, MD Zones: 396 (PAL: 22 x 18, NTSC: 22 x 15), Video Loss, and Tampering
Alarm Inputs7 channels (Alarms 1-6 are local alarm inputs, Alarm 7 is a pulse input)
Alarm Outputs2 channels (1 relay, 1 controllable 12V output)
Playback1
Search ModeTime/Date, Alarm, Motion Detection, and Exact search (to the second)
Playback FunctionsPlay, Pause, Stop, Forward, Fast Playback, Slow Playback, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom
Backup ModeUSB Device / Network
Memory Cards2 SD cards, each up to 256 GB
EthernetRJ-45 port (10/100Mbps)
Wireless NetworkBuilt-in

What are Digital Video Recorders-DVR?

Digital Video Recorders or DVRs are video recorders that convert and record analog video signals. The products, which are connected to the camera system, store and store incoming data. These devices, where images can be monitored, are produced with various features.

What Should Be Considered When Buying a DVR Camera Device?

When buying a DVR camera device, you should pay attention to the number of supported cameras, video compression technology and storage capacity. In addition, face detection and resolution features are also very important. NM-DVR1004 camera devices are unique in all these points in camera features.

How Can I Order a Digital Video Recorder?

You can contact our call center at 0 850 433 18 18 to order NM-DVR1004 camera devices. You can also contact us by filling out the form on our page.
